SHAPET INDUCTION CO. have much years experience with precious metals sector thus developed this induction system for Jewelry manufacturers and goldsmiths. It runs on Induction principle, Absolute homogeneous alloying and uniform metal distribution with reduction in metal losses is achieved due to uniform temperature controlling which avoids the skin effect in SHAPET Induction Systems.
SHAPET Induction system is available in different capacities 500GMS to 2Kg for your convenience of better melting. Both this systems have capability to work in auto mode or manual mode for the convenience of melting and temperature controlling. As chilling unit is standard equipment
SHAPET Induction system, the metal heats with the help of frequency and so there is no loss of heat and metal. In this method there is auto stirring without the need of carbon rod resulting in no loss of metal which remains pure during the entire process.
Specifications
Power Supplier
Three Phase
Voltage
440 V AC
Absorbed Power
5 kW to 8 kW
Capacity of Crucible
1, 2, 4 kg (24 Carat Gold)
Maximum Temperature
1200° C
Melting Time
6 to 9 min
Temperature Measurement
Automatic
Cooling Water Temperature
45° C max
Water Pressure
4 bar
† Brimful Capacity †† Under Standard Condition
Dimensions (mm) L x B x H
Chilling Unit
550.00 x 490.00 x 107.00
Vacuum Pump
265.00 x 550.00 x 365.00
Furnace Unit
810.00 x 610.00 x 107.00
Width (kg - Approx)
Chilling Unit
99 Net
Furnace Unit
145 Net
Benefits
Casting Time 5 to 8 Minute
Safe & Easy Operation
Perfect Mixing Of Alloy Due To Auto Stirring
Faster, Economic and Accurate Castings
Economical and Efficient In Operation
No Product of Combination of Waste Product
Increased Productivity
40% Income Tax Depreciable Under Energy Saving
100% Flameless Device Technology
Highlights
Accurate Casting Temperature Controlling
Advantages of Vacuum Casting Hence Optimal Results
