SHAPET INDUCTION CO. have much years experience with precious metals sector thus developed this induction system for Jewelry manufacturers and goldsmiths. It runs on Induction principle, Absolute homogeneous alloying and uniform metal distribution with reduction in metal losses is achieved due to uniform temperature controlling which avoids the skin effect in SHAPET Induction Systems.

SHAPET Induction system is available in different capacities 2Kg to 5Kg for your convenience of better melting. Both this systems have capability to work in auto mode or manual mode for the convenience of melting and temperature controlling. As chilling unit is standard equipment

SHAPET Induction system, the metal heats with the help of frequency and so there is no loss of heat and metal. In this method there is auto stirring without the need of carbon rod resulting in no loss of metal which remains pure during the entire process.

Specifications
Power Supplier	Three Phase
Voltage	415 V AC
Absorbed Power	1kg Gold=5 kW 2 kg=6.5 kw 4 kg=8kw 5kg=9kW
Capacity of Crucible	1,2, 4, 5 kg (24 Carat Gold)
Maximum Temperature	1200° C
Melting Time	5 to 9 min.
Temperature Measurement	Digital (K - Type)
Cooling Water Temperature	20° C to 35° C
Water Pressure	4 bar
Maximum Water Flow	4 lit/min
† Brimful Capacity   †† Under Standard Condition

Dimensions (mm) L x B x H
Chilling Unit	560.00 x 560.00 x 820.00
Furnace Unit	560.00 x 510.00 x 820.00

Width (kg - Approx)
Chilling Unit	99 Net
Furnace Unit	72 Net

Benefits
Safe & Easy Operation
Continues Melting Of Metal with Chilling Plant
Convenient Layout
Perfect Mixing Of Alloy Due To Auto Stirring
Economical and Efficient In Operation
Increased Productivity
40% Income Tax Depreciable Under Energy Saving
100% Flameless Device Technology

Highlights
Fully Automatic Control
Automatic Power Regulation
Easy To Install
Feather Touch Controls; Simple In Operation
All Safety Precautions Provided
Heat and Power Loss Reduced
Less Power Consumption
Reduce Metal Loss
Melting Time 5 to 8 Minute
